Our mechanical drafters update air con vent locations, duct runs etc on plans

MECHANICAL & BUILDING SERVICES DRAWINGS

Do you need accurate Revit models or clash detection within the model?

Our clients include large engineering firms and installation contractors looking to outsource some of their drafting work in order to meet upcoming deadlines, as well as smaller contractors who don’t have in-house drafting technicians.

Drawable‘s mechanical drafters will update all air conditioning vent locations, duct runs, condenser unit positions, codes and numbering systems

We look after sites including the ABC’s headquarters in Ultimo, Sydney, where we are constantly updating drawings for the mechanical contractors to ensure they are always current.

Here’s a few types of mechanical drawings we generate:

  • As builts & shop drawings
  • Building services
  • HVAC systems, ducts & outlets
  • General ventilation
  • Commercial & residential air conditioning
  • Heating & chilled water systems
  • Condenser water systems
  • Plant & plant room layouts
  • Mechanical detail drawings
  • Piping pathways
  • Revit models including changes

And many other types of drawings.

Get in touch with our draftsmen and we’ll have your mechanical drawings sorted.
